Bolt Type |
3/4" 07IBT/1IBT |
1" 3IBT |
1-1/2" 5,8,10IBT |
2-1/2" 20,25,35,50IBT |
|||||||||||||||||||||
| D | N | Type | L1 | L2 | L3 | D1 | D2 | Type | L1 | L2 | L3 | D1 | D2 | Type | L1 | L2 | L3 | D1 | D2 | Type | L1 | L2 | L3 | D1 | D2 |
| M16 | 24 | 3/4"-S24 | 54 | 32 | 32 | 40 | 40 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| M18 | 27 | 3/4"-S27 | 54 | 32 | 32 | 42 | 42 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| M20 | 30 | 3/4"-S30 | 54 | 33 | 33 | 46 | 44 | 1"-S30 | 59 | 32 | 32 | 54 | 54 |
|
|
|
|
|
|
|
|
|
|
|
|
| M22 | 34 | 3/4"-S34 |
54 |
33 | 33 | 52 | 44 | 1"-S34 | 59 | 32 | 32 | 58 | 58 |
|
|
|
|
|
|
|
|
|
|
|
|
| M24 | 36 | 3/4"-S36 | 57 | 33 | 33 | 54 | 44 | 1"-S36 | 62 | 32 | 32 | 59 | 59 | 1.1/2"-S36 | 85 | 44 | 44 | 74 | 74 |
|
|
|
|
|
|
| M27 | 41 | 3/4"-S41 | 58 | 33 | 33 | 60 | 44 | 1"-S41 | 65 | 38 | 38 | 67 | 54 | 1.1/2"-S41 | 85 | 44 | 44 | 74 | 74 |
|
|
|
|
|
|
| M30 | 46 | 3/4"-S46 | 63 | 38 | 38 | 66 | 44 | 1"-S46 | 65 | 38 | 38 | 74 | 54 | 1.1/2"-S46 | 85 | 44 | 44 | 74 | 74 |
|
|
|
|
|
|
| M33 | 50 | 3/4"-S50 | 65 | 40 | 40 | 71 | 44 | 1"-S50 | 70 | 43 | 43 | 79 | 60 | 1.1/2"-S50 | 90 | 45 | 45 | 79 | 79 |
|
|
|
|
|
|
| M36 | 55 | 3/4"-S55 | 70 | 45 | 45 | 77 | 54 | 1"-S55 | 80 | 42 | 52 | 84 | 60 | 1.1/2"-S55 | 90 | 45 | 45 | 84 | 84 | 2.1/2"-S55 | 100 | 57 | 57 | 86 | 114 |
| M39 | 60 |
|
|
|
|
|
|
1"-S60 | 85 | 45 | 57 | 89 | 60 | 1.1/2"S60 | 100 | 45 | 57 | 94 | 75 | 2.1/2"S60 | 100 | 52 | 52 | 119 | 119 |
| M42 | 65 |
|
|
|
|
|
|
1"-S65 | 84 | 45 | 57 | 98 | 70 | 1.1/2"-S65 | 100 | 45 | 57 | 98 | 80 | 2.1/2"S65 | 100 | 52 | 52 | 119 | 119 |
| M45 | 70 |
|
|
|
|
|
|
1"-S70 | 90 | 50 | 52 | 107 | 70 | 1.1/2"-S70 | 105 | 50 | 62 | 104 | 80 | 2.1/2"S70 | 120 | 67 | 67 | 128 | 128 |
| M48 | 75 |
|
|
|
|
|
|
1"-S75 | 95 | 50 | 65 | 108 | 70 | 1.1/2"-S75 | 110 | 50 | 65 | 118 | 85 | 2.1/2"-S75 | 120 | 67 | 67 | 128 | 128 |
| M52 | 80 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S80 | 115 | 55 | 72 | 118 | 90 | 2.1/2"-S80 | 130 | 71 | 71 | 128 | 128 |
| M60 | 90 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S90 | 125 | 60 | 77 | 139 | 90 | 2.1/2"-S90 | 140 | 61 | 73 | 139 | 139 |
| M64 | 95 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S95 | 130 | 65 | 82 | 139 | 90 | 2.1/2"-S95 | 140 | 66 | 73 | 139 | 139 |
| M68 | 100 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S100 | 135 | 70 | 87 | 144 | 90 | 2.1/2"-S100 | 140 | 71 | 81 | 148 | 130 |
| M72 | 105 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S105 | 135 | 70 | 87 | 149 | 90 | 2.1/2"-S105 | 150 | 77 | 89 | 156 | 130 |
| M76 | 110 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S110 | 135 | 70 | 87 | 158 | 90 | 2.1/2"-S110 | 150 | 72 | 90 | 158 | 130 |
| M80 | 115 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S115 | 135 | 70 | 87 | 159 | 95 | 2.1/2"-S115 | 150 | 82 | 98 | 168 | 130 |
| M85 | 120 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S120 | 135 | 70 | 87 | 168 | 95 | 2.1/2"-S120 | 150 | 82 | 98 | 178 | 130 |
| M90 | 130 |
|
|
|
|
|
|
|
|
|
|
|
|
1.1/2"-S130 | 155 | 93 | 105 | 189 | 95 | 2.1/2"-S130 | 170 | 93 | 114 | 189 | 130 |
| M95 | 135 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.1/2"-S135 | 170 | 93 | 114 | 198 | 130 |
| M100 | 145 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.1/2"-S145 | 170 | 98 | 122 | 210 | 152 |
| M105 | 150 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.1/2"-S150 | 190 | 100 | 140 | 216 | 152 |
| M110 | 155 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.1/2"-S155 | 190 | 100 | 140 | 229 | 152 |
| M115 | 165 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.1/2"-S165 | 190 | 100 | 140 | 241 | 152 |
